In house spectrometer with 36 Elements capable of testing Fe, Ni, Co based materials and also Nitrogen content.
All heats poured are tested on-line on Spectrometer.
All the scrap used are also tested before using.
Specimens are stored for particular period.
In house Universal Testing Machine. In house Hardness Testing Machine. In house Impact test Machine. In house metallurgical microscope. Poured All Heats are Tested & Stored for particular period. Radiography (X-Ray) Dye Penetrate (DPT) Magnetic Particle Test Ultra Sonic Testing (UT) Corrosion Test (IGC) Microstructure & Surface Testing
| Dimensions for holes, Blind holes, Channels, Slots, Grooves | ||||
|---|---|---|---|---|
| Hole Dia. Or Groove/Slot width d(mm) | Greatest Length/Depth | Greatest depth, bottom | ||
| Though hole l | Though hole l | Though hole l | Though hole l | |
| 2 up to 4 | 1xd | 0.6xd | 1xd | 0.6xd |
| 4 up to 6 | 2xd | 1.0xd | 2xd | |
| 6 up to 10 | 3xd | 1.6xd | 3xd | 1.6xd |
| 10 | 4xd | 1.6xd | 4xd | 2.0xd |
| Dimensions for holes, Blind holes, Channels, Slots, Grooves | |
|---|---|
| Hole Dia. Or Groove/Slot width d(mm) | |
| 2 up to 4 | |
| 4 up to 6 | |
| 6 up to 10 | |
| 10 | |
| Greatest Length/Depth | |
| Though hole l | Though hole l |
| 1xd | 0.6xd |
| 2xd | 1.0xd |
| 3xd | 1.6xd |
| 4xd | 1.6xd |
| Greatest Length/Depth | |
| Though hole l | Though hole l |
| 1xd | 0.6xd |
| 2xd | |
| 3xd | 1.6xd |
| 4xd | 1.6xd |
| Dimensions | Normal | Premium | Dimension | Normal | Premium |
|---|---|---|---|---|---|
| up to 1/2 | ± 0.007 | ± 0.003 | up to 12.7 | ± 0.18 | ± 0.08 |
| 1/2 to 1 | ± 0.010 | ± 0.005 | 12.7 to 25.4 | ± 0.25 | ± 0.13 |
| 1 to 2 | ± 0.015 | ± 0.010 | 25.4 to 50.8 | ± 0.38 | ± 0.25 |
| 2 to 3 | ± 0.020 | ± 0.015 | 50.8 to 76.2 | ± 0.51 | ± 0.38 |
| 3 to 4 | ± 0.025 | ± 0.018 | 76.2 to 101.6 | ± 0.64 | ± 0.46 |
| 4 to 5 | ± 0.030 | ± 0.020 | 101.6 to 127.0 | ± 0.76 | ± 0.51 |
| 5 to 6 | ± 0.032 | ± 0.022 | 127.0 to 152.4 | ± 0.81 | ± 0.56 |
| 6 to 7 | ± 0.035 | ± 0.025 | 152.4 to 177.8 | ± 0.89 | ± 0.64 |
| 7 to 8 | ± 0.038 | ± 0.028 | 177.8 to 203.2 | ± 0.96 | ± 0.71 |
| Dimensions | Normal | Premium |
|---|---|---|
| up to 1/2 | ± 0.007 | ± 0.003 |
| 1/2 to 1 | ± 0.010 | ± 0.005 |
| 1 to 2 | ± 0.015 | ± 0.010 |
| 2 to 3 | ± 0.020 | ± 0.015 |
| 3 to 4 | ± 0.025 | ± 0.018 |
| 4 to 5 | ± 0.030 | ± 0.020 |
| 5 to 6 | ± 0.032 | ± 0.022 |
| 6 to 7 | ± 0.035 | ± 0.025 |
| 7 to 8 | ± 0.038 | ± 0.028 |
| up to 12.7 | ± 0.18 | ± 0.08 |
| 12.7 to 25.4 | ± 0.25 | ± 0.13 |
| 25.4 to 50.8 | ± 0.38 | ± 0.25 |
| 50.8 to 76.2 | ± 0.51 | ± 0.38 |
| 76.2 to 101.6 | ± 0.64 | ± 0.46 |
| 101.6 to 127.0 | ± 0.76 | ± 0.51 |
| 127.0 to 152.4 | ± 0.81 | ± 0.56 |
| 152.4 to 177.8 | ± 0.89 | ± 0.64 |
| 177.8 to 203.2 | ± 0.96 | ± 0.71 |
